Biochemistry

Biochemistry Analyzer MCA-11 Plus

4.5

Specification

Panels & Tests
ANEMIA Hepatology Renal
  • Hemoglobulin*
  • Iron
Metabolic
  • Bicarbonate
  • Chloride
  • Copper
  • Glucose
  • Lactate*
  • Magnesium
  • Potassium
  • Sodium
  • Total Protein
  • Triglycerides
  • Zinc
Endocrinology
  • Amylase
  • Adenosine Deaminase*
  • Alkaline Phosphatase
  • Ammonia
  • Bilirubin Direct
  • Bilirubin Total
  • Cholinesterase
  • Gamma GT
  • Total Bile Acids
  • AST/GOT
  • ALT/GPT
  • LDH
BONE
  • Calcium
  • Phosphorus
  • Albumin
  • Creatinine (Kinetic)
  • CSF/Urine Protein*
  • Urea
  • Uric Acid
CARDIAC
  • Angiotensin Converting Enzyme*
  • HDL Cholesterol
  • Homocysteine*
  • LDL Cholesterol
  • Creatine Kinase - NAC
  • Creatine Kinase - MB*
  • Total Cholesterol

Technical Specifications

Analysis Method End point, Fixed‑Kinetics, Kinetics.
Optics 7 standard wavelengths: 340, 405, 505, 545, 570, 630, 700 nm.
Display 7.0" touch screen, 800×480 pixels.
Printer Inbuilt thermal printer, 55 mm printer paper.
Photometric Range 0.000–3.000 Abs.
Resolution 0.001 Abs.
Incubator Inbuilt incubator.
Incubator Temperature 37 °C.
Memory Over 300 programs, up to 200,000 results can be stored.
Operational Environment Temperature: 10–40 °C; Humidity: 30–80 %.
Power Requirement 12 V, 5 A DC.
Interface 4× USB host; 1× USB slave; 1× Ethernet port.
USB (host) supports keyboard, mouse, printer, U‑disk, barcode reader, etc.
USB (slave) for PC connection.
Dimension 330 × 260 × 102 mm (L × W × H).
Weight 2½ kg (approx. 2.5 kg).
