LIFOTRONIC H100 Analyzer
H100 HPLC System is an advanced high-performance liquid chromatography analyzer designed for accurate and reliable HbA1c and hemoglobin variant analysis. The system delivers high precision results with excellent chromatogram clarity and minimal operator intervention. Its user-friendly interface, automated sample handling, and robust column technology ensure consistent performance in high-workload laboratories. H100 supports efficient thalassemia screening and diabetes monitoring with dependable reproducibility. Designed for clinical laboratories, it offers low maintenance requirements and optimized reagent consumption. The H100 is an ideal solution for laboratories seeking quality, efficiency, and long-term performance.
| Efficient | Rapid HbA1c results with Hb variants recognization |
|---|---|
| Innovative | Self-produced column with Hb variants recognization |
| Accurate | New pre-filter design for effective impurities retention |
| Intelligent | Modular Flexbility for one-stop solutions |
Specification
| Methodology | Ion-Exchange High Performance Liquid Chromatography (IEC-HPLC) |
|---|---|
| Test Speed | 96 Seconds/Test (Variant Mode) 350 Seconds/Test (Thalassemia Mode) |
| Throughput | 37 Samples/Hour (Variant Mode) 10 Samples/Hour (Thalassemia Mode) |
| Test Range | 3% - 20% / HbA1c |
| Sample Volume | 5 μL |
| Sample Loader | 50 / 110 + 1 STAT |
| Dimensions | 772 mm x 730 mm x 729 mm |
| Weight | 62 kg |
