AVE 733A Urine Analyzer

Detection Principle

Reflectance Photometry Method

Parameters Detected

Blood (BLD), Leukocytes (LEU), Specific Gravity (SG), pH, Glucose (GLU), Protein (PRO), Nitrite (NIT), Ketones (KET), Urobilinogen (URO), Bilirubin (BIL), Ascorbic Acid (VC), Microalbumin (mALB), Creatinine (CR), Calcium Ions (Ca). Can report Urine Microalbumin/Creatinine Ratio (ACR).

Features
  • High throughputup to ≤ 514 parameter test/Hour
  • Automatic Correction on the influence of non-specificity, pH, SG and color on the results.
  • LCD touch screen with user-friendly interface
  • Automatic Collection of used test strips
  • Bulit-in low noise thermal printer, External printer connectable
  • Automatic results saving and uploading function available
  • With power-on self-checking and automatic fault reporting system. Automatic error warning system. LCD touch screen
  • NMPA approved orginal quality control materials available

    • Specification

    Throughput ≤514 tests/hour
    Test Strips 11 & 14 parameters optional
    Repeatability test result CV<1%
    Accuracy The difference between test results and target values is no more than one level; no false negative result when tested with positive reference solution and no false positive result when tested with negative reference solution
    Stability test result CV <1% with power on of 8 hours
    Printing Built-in thermal printers, external printer (optional)
    Storage ≥100000 test results%
    Relative Humidity 30% - 80%
    Data Interface LIS with barcode input / HL-7
    Working Temperature 5-40℃
    Working Voltage AC 100-240V, 50Hz
    Power 100-240V-50/60Hz, 250VA
    Dimensions 380*320*190mm
    Weight 4.5Kg
